Metal Rolls & Rings
We are the leading Rolls & Rings manufacturing company with Ladle Refining & Vacuum Degassing facility in North India, growing at a fast pace since its inception in the year 1985. We are proud of our strategic achievements.
ALLOY STEEL BASE ROLLS & RINGS (ADAMITE)
These Rolls & Rings are alloyed with Nickel, Chromium, Manganese and Molybdenum with Carbon content between 0.50% and 2.00% as well as little amount of Vanadium is also added for the improvement of better microstructure. So, these are capable of a higher mechanical strength with thermal and wear resistance. These Rolls & Rings undergo a sophisticated multi-stage high temperature Heat Treatment (Double Annealing followed by tempering cycle) to give the combination of hardness, toughness and wear resistance required for the particular application. The lower Carbon grades will have a structure consisting of ferrite and fine Pearlite which, as the Carbon content is raised, transitions to a fully Pearlitic Structure and on to one containing free carbide in a matrix of fine Pearlite and even some Bainite for the highest Carbon grades. All rolls of this material are statically tangentially single poured.
Type of Rolls |
Typical Hardness(Shore°C) |
ACS 38 |
35-40 |
ACS 43 |
40-45 |
ACS 48 |
45-50 |
ACS 52 |
50-55 |
Range of Chemical Composition |
C% |
Mn% |
Si% |
Cr% |
Ni% |
Mo% |
V% |
S% |
P% |
1.20 |
0.50 |
0.30 |
1.00 |
0.60 |
0.20 |
0.05 |
– |
– |
1.85 |
1.00 |
0.60 |
1.55 |
1.25 |
0.50 |
0.10 |
0.045 |
0.045 |
Typical Physical Properties |
|
N/sq.mm. |
Tons/sq.in. |
Tensile Strength |
400 |
25 |
Bending Strength |
850 |
55 |
SPHEROIDAL GRAPHITE (NODULAR) CAST IRON (S.G.I. PEARLITIC) ROLL & RINGS
These Rolls & Rings are essentially an Indefinite Chill type material, but with the Graphite in Nodular form instead of flake and having alloyed with higher % of Nickel & Molybdenum along with Carbon. So these rolls and rings have a much higher Mechanical Strength and allow the use of Iron Rolls in applications which would re-present too high a duty for a flake iron quality due to internal ‘Notch Effect’ of nodular graphite is relatively small. These rolls are very much suitable for the rolling of row products with wide range of applications due to its hardness penetration, good wear resistance and tough necks, and this material has become a benchmark.
Range of Chemical Composition |
C% |
Mn% |
Si% |
Cr% |
Ni% |
Mo% |
Cu% |
S% |
P% |
3.00 |
0.20 |
1.20 |
0.20 |
1.50 |
0.20 |
– |
– |
– |
4.00 |
1.00 |
2.50 |
1.00 |
3.00 |
1.00 |
0.25 |
0.015 |
0.060 |
Typical Physical Properties |
|
N/sq.mm. |
Tons/sq.in. |
Tensile Strength |
400 |
25 |
Bending Strength |
850 |
55 |
Typical Hardness(Shore°C)
|
SG-PC47 |
45-50 |
SG-PC50 |
48-53 |
SG-PC53 |
50-55 |
SG-PC55 |
53-58 |
SG-PC58 |
55-60 |
SG-PC60 |
58-63 |
SG-PC63 |
60-65 |
SG-PC65 |
62-67 |
SG-PC67 |
65-70 |
SG-PC73 |
70-75 |
Application
|
Product |
Type of Mill |
Position |
Billets & Sheet Bar |
2 & 3 High |
Finishing |
Billets & Sheet Bar |
Continuous |
All Positions |
Beams |
Universal |
Vertical |
Medium Sections |
2 & 3 High |
Intermediate & Finishing |
Small & Medium Sections |
Straightening |
|
Bar & Small Sections |
2 & 3 High |
All Positions |
Rod |
2 & 3 High |
Roughing & Intermediate |
Plate |
2 High |
Finishing |
Plate |
3 High |
All Positions |
Plate |
4 High |
Roughing & Finishing |
Sheet |
2 & 3 High |
Finishing |
Wide Strip |
2 & 4 High |
Roughing |
TMT & Wire Rod |
2 High |
Roughing & Intermediate |
S.G.I. BAINITIC ACCICULAR ROLLS & RINGS
These Rolls & Rings are stronger and more wear resistance with respect of S.G.I. Pearlitic Rolls and Rings are capable of much higher hardness because S.G.I. Bainitic Accicular is more alloyed with very higher % of Nickel and Molybdenum than the S.G.I. Pearlitic and as a result, the acicular roll material has a bainitic matrix with increased carbide. The name of this material is based on its constituents of nodular graphite and carbides (needle-like) bainitic matrix, also called Lower Baintic. These Rolls become a benchmark in the rolling of long product and is suitable for a wide range of applications due to its hardness penetration, good wear resistance and tough necks.
Range of Chemical Composition |
C% |
Mn% |
Si% |
Cr% |
Ni% |
Mo% |
Cu% |
S% |
P% |
3.00 |
0.20 |
1.20 |
0.20 |
2.50 |
0.40 |
– |
– |
– |
4.00 |
1.00 |
2.50 |
1.00 |
4.50 |
1.20 |
0.20 |
0.015 |
0.060 |
Typical Physical Properties |
|
N/sq.mm. |
Tons/sq.in. |
Tensile Strength |
570 |
36 |
Bending Strength |
1000 |
65 |
Typical Hardness(Shore°C)
|
SG-AC 55 |
53-58 |
SG-AC 58 |
55-60 |
SG-AC 60 |
58-63 |
SG-AC 63 |
60-65 |
SG-AC 65 |
63-68 |
SG-AC 68 |
65-70 |
SG-AC 70 |
68-73 |
SG-AC 73 |
68-75 |
SG-AC 75 |
72-77 |
SG-AC 77 |
75-80 |
Application
|
Product |
Type of Mill |
Position |
Sheet & Coil |
Temper |
Back Up Rolls |
Sheet & Coil |
Double Reduction |
Back Up Rolls |
Sheet & Coil |
2 High Skin Pass |
|
Rod |
2 & 3 High |
Intermediate & Finishing |
Bar |
2 & 3 High |
Finishing |
Small Sections |
2 & 3 High |
Roughing & Finishing |
Medium Sections |
2 & 3 High |
Finishing |
Beams |
Universal |
Horizontal Rolls & Sleeves |
Small & Medium Sections |
Straightening |
|
Plate |
2 & 3 & 4 High |
|
Sheet |
2 & 3 High |
Finishing |
Wide Strip |
2 & 4 High |
Roughing & Finishing |
TMT & Wire Rod |
2 High |
Roughing & Intermediate |
ALLOY INDEFINITE CHILLED IRON ROLLS
Alloys Indefinite Chill Iron Rolls have a structure consisting of more flake graphite with few carbides in a Pearlitic Matrix. Harder grades have a Bainitic-Martensitic matrix with an increased amount of carbides. The presence of flake graphite improves spalling resistance and also enhances resistance to fire-cracking. All of these properties combined with the excellent surface make AIC Alloy Indefinite Chill very suitable for rolling flats sections and similar products where surface finish is critical. Due to alloy additions, hardness penetration is better than that of a clear chill roll and this material may be used in applications with deeper grooves such as small and medium section rolling and also for finishing billets. All rolls of this material are statically Tangentially Single Poured.
Range of Chemical Composition |
C% |
Mn% |
Si% |
Cr% |
Ni% |
Mo% |
V% |
S% |
P% |
2.80 |
0.60 |
0.50 |
0.80 |
0.80 |
0.30 |
– |
– |
– |
3.80 |
1.10 |
1.00 |
1.20 |
1.20 |
0.60 |
0.10 |
0.060 |
0.100 |
Typical Physical Properties |
|
N/sq.mm. |
Tons/sq.in. |
Tensile Strength |
200 |
12 |
Bending Strength |
320 |
20 |
Application
|
Product |
Type of Mill |
Position |
Plate |
2 & 3 & 4 High |
Roughing & Finishing |
Medium & Narrow Strip |
2 High |
Roughing |
Billet & Sheet Bar |
2 & 3 High |
Finishing |
Medium Sections |
Continuous |
Intermediate & Finishing |
Medium Sections |
2 & 3 High |
Intermediate & Finishing |
Light Sections |
2 & 3 High |
All Positions |
Bar |
2 & 3 High |
All Positions |
Rod |
2 & 3 High |
Roughing & Intermediate |
Medium & Light Sections |
Straightening |
|
TMT |
2 High |
Intermediate & Finishing |
